Trotec BZ05 - Device Overview; Description and Features; Device Depiction; Technical Specifications

4 EN
thermohygrometer BZ05
Information about the device
Device description
The thermohygrometer is a battery-powered measuring device
indicating the current indoor climate.
It comes with the following functional properties and equipment
features:
• Simultaneous indication of time or date, room temperature,
feel-good indication and humidity level
• Alarm function
• Indication of recorded minimum and maximum values for
temperature and relative humidity
• Switching option between °C and °F
• Reset function
• Integrated stand for table installation
• Holder for wall mounting
Device depiction
1
3
7
2
6
4
5
8
9
10
12
11
13
14
No. Designation
1 Time/date/wake-up time display
2 Temperature indication (°C/ °F)
3 Relative humidity indication
4 Feel-good indication
5 MODE button
6 ADJ button
7 MEMO button
8 Hour indication
9 Minute indication
10 Battery compartment
11 RESET button
12 °C/°F button
13 Fold-out stand
14 Holder for wall mounting
Technical data
Parameter Value
Model
BZ05
Display LCD (monochrome)
Relative humidity
Measuring range 10 %RH to 90 %RH
Accuracy ±5 %RH
Resolution 1%
Air temperature
Measuring range 0°C to 50 °C or 32°F to 122 °F
Accuracy ±1 °C or ±1.8 °F
Measuring range
resolution
0.1°C/°F
Ambient conditions
Operation 0°C to 50°C or 32°F to 122°F
and 80%RH (non-condensing)
Storage -20°C to 60°C or -4°F to 140°F
and 80%RH (non-condensing)
Power supply 1battery of typeAAA, 1.5V
Dimensions
(lengthx widthx height)
approx. 108mmx 15mmx 60mm
Weight (incl. battery) approx. 74g
Scope of delivery
• 1x Device BZ05
• 1x Battery, typeAAA, 1.5V
• 1x manual
