Trotec PAE 25 User Manual

EN 4
Operating manual – air cooler PAE 25
Device depiction
1
2
3
4
5
7
8
9
11
Timer/
Preset
Speed
Wind
Direction
Mode
ON/OFF
Cooling
Light
6
10
No. Designation
1 Transport handle
2 Air inlet with air filter and honeycomb filter
3 Wheels
4 Honeycomb filter
5 Ice packs
6 Remote control
7 Air filter
8 Water tank with filling level indicator
9 Air outlet with adjustable ventilation flaps
10 Air flaps for swing function
11 Control panel
Transport and storage
Notice
If you store or transport the device improperly, the
device may be damaged.
Note the information regarding transport and storage of
the device.
Transport
Before transporting the device, proceed as follows:
• Switch off the device.
• Hold onto the mains plug while pulling the power cable out
of the mains socket.
• Empty the water tank.
• To make the device easier to transport, it is fitted with
wheels.
• Do not use the power cable to drag the device.
• Only wheel the device on a level and smooth surface.
After transporting the device, observe the following:
• Set up the device in an upright position after transport.
Storage
Before storing the device, proceed as follows:
• Empty and clean the water tank prior to storage (see
chapter Maintenance).
• Allow the honeycomb filter to dry prior to storage.
Otherwise the device may distribute a musty smell after
restart.
When the device is not being used, observe the following
storage conditions:
• dry and protected from frost and heat
• in an upright position where it is protected from dust and
direct sunlight
• with a cover to protect it from invasive dust if necessary
• Place no further devices or objects on top of the device to
prevent it from being damaged.
• Remote batteries from the remote control.

Trotec PAE 25 Specifications

General

Brand	Trotec
Model	PAE 25
Category	Air Conditioner
Language	English
