Trotec PAE 49 - Refilling and Shutdown; Refilling Water and Ice Packs; Device Shutdown Procedure

EN 15
air cooler PAE 49 / PAE 50
1. Disconnect the device from the mains before refilling water
or putting ice packs into the device.
2. Open the water funnel(3).
3. Ensure tight fit of the rubber stopper(10), for otherwise
there might be uncontrollable water leakage.
4. Fill the water tank(11) with fresh drinking water only.
Optionally, you can add ice cubes made of drinking water
for additional cooling.
ð Observe the minimum and maximum filling level at the
filling level indicator.
The water tank must be filled up to minimum filling level
to enable pump operation.
5. If required, put the ice packs into the water tank(11) for
additional cooling. The ice packs can be inserted in two
ways.
ð Option1: Insert the ice packs into the device through
the water funnel.
ð Option2: Remove the evaporation filter(5) and the air
filter(9) at the rear of the device and insert the ice
packs.
6. Close the flap of the water funnel(3) or reinsert the
evaporation filter(5) and the air filter(9).
7. Make sure that the device is neither damp nor wet on the
outside. Otherwise wipe it dry.
Auto stop function
If the water tank is empty, the Humidity LED(27) flashes.
In air cooling mode, the fan continues running; in air freshening
mode, the device will stop automatically after a while.
Shutdown
Warning of electrical voltage
Do not touch the mains plug with wet or damp hands.
• Switch off the device.
• Hold onto the mains plug while pulling the power cable out
of the mains socket.
• Empty and clean the water tank (see chapter
Maintenance).
• Clean the device according to the Maintenance chapter.
• Store the device according to the Storage chapter.
