Trotec TA300 User Manual

EN 5
hot-wire anemometer TA300
Technical data
Parameter Value
Dimensions of the
device
(height x width x depth)
210x 75x 50mm
Display Dual LC display,
46.7 x 60mm
Weight (packaging
excluded)
280g
Power supply 1 x 9V battery
Operating conditions 0°C to 50°C, < 80% RH
Sampling after approx. 0.8 seconds
Air velocity
Measuring range m/s: 0.1 to 25.0
ft/min: 20 to 4925
km/h: 0.3 to 90
MPH: 0.2 to 55.8
kn: 0.2 to 48.5
Resolution m/s: 0.01
ft/min: 1
km/h: 0.1
MPH: 0.1
kn: 0.1
Accuracy m/s: ±5% of the measured value
+1digit
Air volume flow
Measuring range CFM: 0.001 to 999999 ft
3
/min
CMM: 0.001 to 999999 m
3
/min
Temperature
Measuring range °C: 0 to 50°C
°F: 32.0 to 122.0°F
Resolution °C: 0.1
°F: 0.1
Accuracy °C: ±1.0°C
°F: ±1.8°F
Scope of delivery
• 1x Hot-wire anemometer TA300
• 1 x 9V battery
• 1x Hot-wire sensor
• 1x Charging cable
• 1 x Transport case
• 1 x Mini USB cable
• 1 x CD-ROM with Manometer&Flowmeter software
• 1x Quick guide
• 1x Calibration certificate
Transport and storage
Note
If you store or transport the device improperly, the
device may be damaged.
Note the information regarding transport and storage of
the device.
Transport
For transporting the device, use the transport case included in
the scope of delivery in order to protect the device from external
influences.
Storage
When the device is not being used, observe the following
storage conditions:
• dry and protected from frost and heat
• protected from dust and direct sunlight
• For storing the device, use the transport case included in
the scope of delivery in order to protect the device from
external influences.
• The storage temperature is the same as the range given in
the Technical data chapter.
• Remove the battery from the device.

Trotec TA300 Specifications

General

Brand	Trotec
Model	TA300
Category	Measuring Instruments
Language	English
