Trotec TCH 18 E - Maintenance and Technical Data; Pre-Maintenance Safety and Cleaning

8 EN
convector TCH 18 E / TCH 19 E
The device still does not operate correctly after these
checks:
Please contact the customer service. If necessary, bring the
device to an authorised specialist electrical company or to
Trotec for repair.
Maintenance
Activities required before starting maintenance
Warning of electrical voltage
Do not touch the mains plug with wet or damp hands.
• Switch the device off.
• Hold onto the mains plug while pulling the power cable out
of the mains socket.
• Allow the device to cool down completely.
Warning of electrical voltage
Tasks which require the device to be opened must
only be carried out by authorised specialist
companies or by Trotec.
Cleaning the housing
Warning of electrical voltage
Never immerse the device in water!
Clean the housing with a soft, damp and lint-free cloth. Make
sure that no moisture enters the housing. Protect electrical
components from moisture. Do not use any aggressive cleaning
agents such as cleaning sprays, solvents, alcohol-based or
abrasive cleaners to dampen the cloth.
Wipe the housing dry after cleaning.
Technical annex
Technical data
Parameter Value
Model TCH18E TCH19E
Heating capacity
level1:
level2:
level3:
750W
1250W
2000W
750W
1250W
2000W
Mains connection 1/N/PE
220 – 240 V
~50 – 60 Hz
1/N/PE
220 – 240 V
~50 – 60 Hz
Max. power
consumption
2000W 2000W
Nominal current
consumption
8.7A 8.7A
Fusing 10A 10A
Type of protection IP20 IP20
Plug type Schuko plug
CEE7/7
Schuko plug
CEE7/7
Cable length 1.2 m 1.2 m
Dimensions
(depth x width x height)
200 x 520x
345mm
200 x 470x
332mm
Minimum distance to
walls and other objects
top (A):
rear (B):
sides (C):
front (D):
100 cm
50 cm
50 cm
50 cm
100 cm
50 cm
50 cm
50 cm
Weight 2.0kg 2.0kg
