Operating manual – fan heater TFC 13 E / TFC 14 E
Notice
Wait for at least 3 minutes after maintenance and
repair work. Only then switch the device back on.
Your device still does not operate correctly after these
checks?
Please contact the customer service. If necessary, bring the
device to an authorized specialist electrical company or to
Trotec for repair.
Maintenance
Activities required before starting maintenance
Warning of electrical voltage
Do not touch the mains plug with wet or damp hands.
• Switch the device off.
• Hold onto the mains plug while pulling the power cable out
of the mains socket.
• Allow the device to cool down completely.
Warning of electrical voltage
Tasks which require the housing to be opened
must only be carried out by authorised specialist
companies or by Trotec.
Cleaning the housing
Warning of electrical voltage
Never immerse the device in water!
Clean the housing with a soft, damp and lint-free cloth. Ensure
that no moisture enters the housing. Protect electrical
components from moisture. Do not use any aggressive cleaning
agents such as cleaning sprays, solvents, alcohol-based or
abrasive cleaners to dampen the cloth.
Wipe the housing dry after cleaning.
Technical annex
Technical data
Parameter Value
Model TFC 13 E / TFC 14 E
Heating capacity
level1:
level2:
level3:
ventilation only
700W
1400W
Air volume 141.98m³/h
Operating range -10°C to +25°C
Mains connection 220 – 240V/ 50Hz
Max. power input 1400 W
Nominal current consumption 6.1 A
Fusing 10 A
Plug type Schuko plug CEE7/17
Cable length 1.5 m
Sound pressure level (1m distance) 48 dB(A)
Protection type IP20
Protection class
II /
Overheating protection 80 °C
Dimensions (depthx widthx height) 120 x 195x 255mm
Minimum distance to walls and
other objects
A: top:
B: rear:
C: side:
D: front:
100 cm
100 cm
100 cm
100 cm
Weight 1 kg
