Trotec TGP 1000 E - Technical Annex; Technical Data

12 EN
garden pump TGP 1000 E
Technical annex
Technical data
Parameter Value
Model TGP1000E
Max. feed rate 3300 l/h
Max. pump height 42 m
Max. suction height 7 m
Max. air pressure 4.2 bar
Max. water temperature 35°C
Power supply 230 V ~ 50 Hz
Power consumption 1000 W
Protection type of the pump IPX4
Protection type of the mains
plug
IP44
Connection type CEE 7/7
Cable length 1.2 m
Protection class I
Weight 6 kg
Dimensions
(lengthx widthx height)
210x 330x 200(mm)
Max. particle size 2 mm
Pressure connection 1" internal thread
Suction connection 1" internal thread
Sound values according to EN ISO 3744:1995
Sound pressure level L
pA
72 dB(A)
Sound power level L
WA
88 dB(A)
Uncertainty K
WA
2 dB(A)
Schematic representation
TGP 1000 E
max.
35°
7 m max.
42 m max.
