P. O. Box 1386, 97 KENT AVENUE, KITCHENER, ON N2G 4J1
Printed In USA
OperatOrs Manual
Safe Operation Practices • Set-Up • Operation • Maintenance • Service • Troubleshooting • Warranty
WARNING
READ AND FOLLOW ALL SAFETY RULES AND INSTRUCTIONS IN THIS MANUAL
BEFORE ATTEMPTING TO OPERATE THIS MACHINE.
FAILURE TO COMPLY WITH THESE INSTRUCTIONS MAY RESULT IN PERSONAL INJURY.
769-09587
12.20.13
Automatic Lawn Tractor

Questions and Answers

  • K
    Kimberly TateAug 20, 2025
    Why Troy-Bilt Automatic Lawn Tractor Lawn Mower engine fails to start?
    • D
      Douglas HarrisAug 20, 2025
      If your Troy-Bilt Lawn Mower engine fails to start, several factors could be at play. First, ensure the PTO/Blade is disengaged by placing the knob or lever in the OFF position. Check that the spark plug wire is securely connected to the spark plug. Verify that the fuel tank isn't empty and contains clean, fresh gas (less than 30 days old). Make sure the choke is activated by placing the throttle control in the CHOKE position. Inspect the spark plug for faults, cleaning, adjusting the gap, or replacing it as necessary. Check for a blocked fuel line, cleaning it and replacing the fuel filter. If the engine is flooded, crank it with the throttle in the FAST position. Ensure the parking brake is engaged, and the throttle control lever is in the correct starting (FAST) position.
  • K
    Kathleen DayAug 22, 2025
    Why Troy-Bilt Lawn Mower engine idles rough?
    • T
      Tara HallAug 22, 2025
      If your Troy-Bilt Lawn Mower engine idles roughly, the spark plug may be fouled, faulty, or have a gap that is too wide. Replace the spark plug and set the plug gap correctly. Another potential cause is a dirty air cleaner. Replace the air cleaner element and/or clean the pre-cleaner, if your mower is equipped with one.
  • N
    Natasha HunterAug 25, 2025
    What to do if Troy-Bilt Automatic Lawn Tractor engine fails to start?
    • J
      Joe LaneAug 25, 2025
      If your Troy-Bilt Lawn Mower engine won't start, make sure the PTO knob (or lever) is disengaged (OFF) and the parking brake is engaged. Connect the wire(s) to the spark plug(s), and set the throttle lever to the FAST position. Pull out the CHOKE control (if equipped) or place the throttle control in the CHOKE position. Ensure the fuel tank is filled with clean, fresh gas (less than 30 days old). Clean the fuel line or replace the fuel filter if necessary. Clean, adjust the gap, or replace the spark plug. Finally, crank the engine with the throttle in the FAST position.
  • J
    Jacqueline GardnerAug 26, 2025
    How to fix Troy-Bilt Automatic Lawn Tractor Lawn Mower that idles poorly?
    • J
      Jacob HinesAug 26, 2025
      If your Troy-Bilt Lawn Mower idles poorly, try these steps: Replace the spark plug(s). Set the plug(s) gap. Replace the air cleaner cartridge/element or clean the pre-cleaner, if equipped.
  • J
    Jason VasquezAug 30, 2025
    How to improve mulching with Troy-Bilt Lawn Mower?
    • S
      Stephanie McdanielAug 30, 2025
      If your Troy-Bilt Lawn Mower isn't mulching grass effectively, several factors could be the cause. Ensure the engine speed isn't too low by placing the throttle in the FAST (rabbit) position. Avoid mulching when the grass is wet. If the grass is excessively high, mow once at a high cutting height, then mow again at your desired height, or make a narrower cutting swath. Lastly, a dull blade can hinder mulching, so sharpen or replace the blade.
  • A
    Alexander WeaverSep 1, 2025
    What to do if Troy-Bilt Automatic Lawn Tractor Lawn Mower causes uneven cut?
    • I
      ituckerSep 1, 2025
      If your Troy-Bilt Lawn Mower is producing an uneven cut, several factors could be responsible. First, ensure the mower deck is leveled properly by performing a side-to-side deck adjustment. A dull blade can also cause an uneven cut, so sharpen or replace the blade. Finally, check the tire pressure in all four tires to ensure it's even.
  • M
    Mario MasonSep 3, 2025
    Why Troy-Bilt Lawn Mower engine overheats?
    • C
      Chad GutierrezSep 3, 2025
      If your Troy-Bilt Lawn Mower engine is overheating, check the engine oil level and fill the crankcase with the proper amount and weight of oil. Also, ensure that the airflow is not restricted by cleaning grass clippings and debris from around the engine’s cooling fins and blower housing.
  • S
    Sarah ThorntonSep 5, 2025
    How to reduce vibration in Troy-Bilt Lawn Mower?
    • M
      Mallory SteeleSep 5, 2025
      If your Troy-Bilt Lawn Mower is experiencing excessive vibration, the cutting blade might be loose or unbalanced. Tighten the blade and spindle, and balance the blade. Alternatively, the cutting blade could be damaged or bent, in which case you should replace it.
  • E
    Elizabeth Turner DDSSep 7, 2025
    What to do if Troy-Bilt Lawn Mower engine hesitates at high RPM?
    • R
      Ryan MooreSep 7, 2025
      If your Troy-Bilt Lawn Mower engine hesitates at high RPM, the spark plug gap might be too close. Remove the spark plug and reset the gap.
  • N
    Natalie DeanSep 9, 2025
    Why does my Troy-Bilt Automatic Lawn Tractor engine run erratic?
    • R
      robert23Sep 9, 2025
      If your Troy-Bilt Lawn Mower engine is running erratically, try these solutions: Push the CHOKE control in (if equipped) or move the throttle control out of the CHOKE position. Check and tighten the spark plug wire(s). Clean the fuel line and ensure the tank is filled with clean, fresh gasoline (less than 30 days old). Replace the fuel filter, if equipped. Clear the vent or replace the cap if it's damaged. You may also need to drain the fuel tank and refill it with clean, fresh gasoline. Lastly, replace the air cleaner cartridge/element or clean the pre-cleaner, if equipped.

Summary

TROY-BILT OPERATORS MANUAL

Automatic Lawn Tractor

Identifies the type of equipment covered by this manual.

WARNING: Read and Follow Safety Instructions

Emphasizes critical safety warnings for operating the machine.

To The Owner

Thank You

Expresses gratitude for purchasing the equipment.

Record Product Information

Instructions on how to record model and serial numbers for support.

Customer Support

Provides contact information for customer assistance and service.

Important Safe Operation Practices

General Operation Safety Rules

Details essential safety rules for operating the machine.

Slope Operation Safety

Service

Safe Handling of Gasoline

Provides critical safety guidelines for handling gasoline.

Safety Symbols Guide

Slope Gauge Instructions

Assembly & Set-Up

Tractor Set-Up Notes

General notes regarding tractor specifications and model variations.

Connecting the Battery Cables

Step-by-step instructions for connecting the tractor battery cables.

Shipping Brace Removal

Instructions for removing the shipping brace before operation.

Attaching The Steering Wheel

Attaching The Seat

Tire Pressure Recommendations

Gas and Oil Fill-up Procedures

Setting Deck Gauge Wheels

Attaching the Hood Scoop

Controls & Features

Throttle and Choke Lever

Details the function and operation of the throttle and choke control.

Ignition Switch Module Operation

Explains how to operate the ignition switch for starting the engine.

Shift Lever Operation

Describes the positions and operation of the shift lever.

Brake Pedal Operation

Details the function and operation of the brake pedal.

Parking Brake Engagement

Instructions on how to set and release the parking brake.

Drive Pedal Operation

Deck Lift Lever Function

PTO (Blade Engage) Lever

Operation

Safety Interlock Switches

Explains the tractor's safety interlock system for operator protection.

Reverse Caution Mode

Instructions for operating the tractor in reverse with blades engaged.

Engaging the Parking Brake

Setting the Cutting Height

Starting the Engine

Stopping the Engine

Driving The Tractor

Driving On Slopes Safely

Engaging the Blades

Using the Deck Lift Lever

Mowing Best Practices

Headlights Operation

Maintenance & Adjustments

General Maintenance

General safety warnings and instructions before performing maintenance.

Engine Maintenance

Instructions for engine maintenance as per the operator's manual.

Changing Engine Oil and Filter (Briggs & Stratton)

Procedure for changing oil and filter on Briggs & Stratton engines.

Changing Engine Oil (Kohler)

Procedure for changing engine oil on Kohler engines.

Air Cleaner Service

Spark Plug Maintenance

Lubrication Points

Engine Lubrication

Pivot Points & Linkage Lubrication

Rear Wheels Maintenance

Front Axles Lubrication

Battery Maintenance

Cleaning Battery Terminals

Battery Failure Causes

Cleaning the Engine and Deck

Deck Wash System Operation

Adjustments Overview

Leveling the Deck

Front To Rear Deck Adjustment

Procedure for adjusting the deck's front to rear tilt.

Side to Side Deck Adjustment

Seat Adjustment Instructions

Parking Brake Adjustment

Maintenance Schedule

Service

Cutting Deck Removal

Step-by-step guide to removing the cutting deck from the tractor.

Tire Specifications

Battery Safety

Jump Starting Procedures

Battery Charging

Fuse Location and Replacement

Cutting Blades Removal and Sharpening

Changing the Deck Belt

Changing the Transmission Drive Belt

Troubleshooting Guide

Attachments & Accessories List

FOUR YEAR SUPREME WARRANTY

FEDERAL and;or CALIFORNIA EMISSION CONTROL WARRANTY STATEMENT

YOUR WARRANTY RIGHTS AND OBLIGATIONS

Details owner's rights and responsibilities regarding emissions warranty.

MANUFACTURERS WARRANTY COVERAGE

Outlines the manufacturer's warranty coverage for emission control systems.

OWNERS WARRANTY RESPONSIBILITIES

Specifies owner's duties for maintaining and presenting equipment for warranty.

GENERAL EMISSIONS WARRANTY COVERAGE

Explains the general terms and conditions of the emissions warranty coverage.

WARRANTED PARTS LIST

Replacement Parts List

Troy-Bilt Automatic Lawn Tractor Specifications
