25
Models D609, G609, U609 & X609
REF.
NO.
PART NO. DESCRIPTION
1 783-1346 Grill Support Bracket (9-style)
2 710-0599 Self-tapping Screw, 1/4-20 x .5
3 710-0528 Hex Cap Screw, 5/16-18 x 1.25
4 710-0924 Phillips Pan Screw, 1/4-20 x .75
5 710-1017 Truss Phillips Screw, 1/4-20 x .625
6 725-1741 Ignition Switch
7 726-0272 Clamp, 9/16
8 710-0642 Self-tapping Screw, 1/4-20 x .75
9 712-0292 U-type Speed Nut, 1/4-20
10 736-0270 Bell Washer, .265 x .75 x .062
11 725-1976 Systems Indicator Monitor
12 712-3004A Hex Nut, 5/16-18
13 731-2119A Grille (9-style)
14 731-0511 Trim Strip, 4
15 725-0175 Cable Tie, 3/16 x .05 x 7.4
16 746-1085 Choke Knob/Cable (Model G609G)
17 783-0783 Hood (9-style)
18 783-0784 RH Side Panel (9-style)
19 783-0785 LH Side Panel (9-style)
20 731-2637 Headlight Lens (9-style)
21 747-1162A Hood Hinge Rod
22 625-0051 Headlight Assembly
23 710-0604A Self-tapping Screw, 5/16-18 x .625
24 751-0603 Fuel Cap
25 751-0658C Fuel Tank, Three-gallon
751-0659A Fuel Tank, Two-gallon (Model
D609G)
26 725-1745 Ignition Key w/ plastic cover
725-1744 Ignition Key w/o plastic cover
27 710-0895 Self-tapping Screw, 1/4-15 x .75
28 710-3217 Truss Phillips Screw, #8-32 x .375
29 712-0142 Hex Nut, #8-32
30 731-1857 Throttle Control Knob
31 731-2122C Dash Panel, 8/9-style, Manual PTO
32 731-2226 Cruise Control Button
33 731-2227 Parking Brake Button
34 736-0142 Flat Washer, 9/32 x 1/2 x 1/16
35 747-1196 Brake/Cruise Pivot Rod
36 749-1087A Dash Support Tube
37 712-3010 Hex Nut, 5/16-18
38 731-2270 Hood Plenum (Model G609G)
N/A Hood Plenum (Model D609G)
39 726-3046 Ratchet Clip
40 736-0119 Lock Washer, 5/16
41 726-0201 Speed Nut, .3125
42 736-3078 Flat Washer, .349 x 1.0 x .063
43 710-1238 Screw, 5/16-18 x .875 (Grade 5)
629-0469A Headlight Wire Harness (Not Shown)
629-1071 Tractor Wire Harness (Not Shown)
REF.
NO.
PART NO. DESCRIPTION
NOTE: For painted parts, please refer to the list of color codes below.
Please add the applicable color code, wherever needed, to the part
number to order a replacement part. For instance, if a part numbered
700-xxxx is painted Powder Black, the part number to order would be
700-xxxx-0637.
Red: 0638
Oyster Gray: 0662
Powder Black: 0637
