Troy-Bilt D609G - Page 27

27
REF.
NO.
PART
NO.
DESCRIPTION
1 747-1130A Deck Stabilizer Rod
2 683-0197 Lift Shaft Assembly
3 711-0332 Clevis Pin, .5 x .78
4 712-0206 Hex Nut, 1/2-13
5 712-0431 Flange Lock Nut, 3/8-16
6 712-3004A Flange Lock Nut, 5/16-18
7 712-3083 Hex Nut, 1/2-13
8 714-0104 Internal Cotter Pin
9 714-0145 Internal Cotter Pin
10 716-0106 E-ring
11 720-0311 Handle Grip
12 732-0874 Torsion Spring
13 732-1184 Extension Spring, .872 x 3.4
14 736-0275 Flat Washer, 5/16
15 736-0921 Lock Washer, 1/2
16 736-3019 Flat Washer, .31 x 1.062 x .134
17 736-3084 Flat Washer, .51 x 1.12 x .06
18 738-0138A Hex Cap Screw, 5/16-18 x .62
19 738-0143 Shoulder Screw, 3/8-16
20 741-0225 Hex Flange Bearing
21 741-0715 Snap Flange Bearing
22 746-0968 Lift Cable, 16.16
23 747-1111 Lift Handle
24 756-1154 Roller Pulley
25 783-0678A Arm Lift
26 783-0720A Deck Stabilizer Bracket
27 710-0260A Carriage Bolt, 5/16 x .62
28 710-0604A Self-tapping Screw, 5/16-18 x .625
29 710-0895 Self-tapping Screw, 1/4-15 x .75
30 731-1990 Lift Lever Cover
31 731-2104B Shift Lever Cover w/ Cup Holder
32 736-3078 Flat Washer, .349 x 1.0 x .063
33 783-0677 Lift Adjustment Bracket
34 783-0685B Fender
35 783-1489 Seat Mounting Bracket
36 710-1268 Screw, #10-16 x .375
37 712-3027 Hex Flange Lock Nut, 1/4-20
38 720-0309A Seat Adjuster Grip
39 731-1989 Spacer
40 732-0499 Compression Spring, .41 x 1.5
41 736-0175 Spring Washer, .265 x .562 x .025
42 736-0204 Flat Washer, .344 x .62 x .03
43 738-0137A Shoulder Screw, .340 x .285,1/4-20
44 738-1007 Shoulder Screw, .50 x .50, 3/8-16
45 783-0611 Seat Stop
46 783-0738 Seat Pivot Bracket
47 783-0739 Seat Adjustment Lever
48 783-0753 Seat Adjustment Selector
49 757-0348A High Back Seat, Black
50 735-0656 RH Foot Pad
51 735-0657 LH Foot Pad
726-3046 Foot Pad Clips (Not Shown)
52 714-0111 Cotter Pin
53 731-0511 Trim Strip
54 783-0209A Seat Lift Bracket
55 726-0201 Speed Nut
REF.
NO.
PART
NO.
DESCRIPTION
Models D609, G609, U609 & X609
NOTE: For painted parts, please refer to the list of color codes below.
Please add the applicable color code, wherever needed, to the part
number to order a replacement part. For instance, if a part numbered
700-xxxx is painted Powder Black, the part number to order would be
700-xxxx-0637.
Red: 0638
Oyster Gray: 0662
Powder Black: 0637
