Troy-Bilt D609G - Page 29

29
REF.
NO.
PART
NO.
DESCRIPTION
1 731-1291A Pivot Bar End Cap
2 710-1238 Self-tapping Screw, 16-18 x .625
3 783-0726B RH Pivot Support Bracket
4 783-0727A LH Pivot Support Bracket
5 783-0728 Pivot Bar Bracket
6 710-0723 Hex Cap Screw, 3/8-16 x 1
7 711-1408 RH Drag Link
8 711-1655 LH Drag Link
9 712-0240 Jam Nut, 7/16-20
10 712-0241 Hex Nut, 3/8-24
11 712-0431 Flange Lock Nut, 3/8-16
12 712-0459 Flange Lock Nut, 7/16-20
13 712-3004A Flange Lock Nut, 5/16-18
14 717-1550D Steering Gear, 11/90 Ratio
15 717-1554 Steering Pinion Gear
16 723-0448A Ball Joint, 7/16-20
17 736-0169 Lock Washer, 3/8
18 736-3084 Flat Washer, .51 x 1.12 x .06
19 738-1001A Steering Shaft, .625 OD x 24.4
20 741-0475 Plastic Bushing, .38 ID
21 741-0656 Hex Flange Bearing, 5/8
22 738-0372B Shoulder Spacer, .38 ID
23 731-2624 Steering Wheel, 13.25
24 731-2625 Steering Wheel Cap
25 638-0019A LH Axle Assembly, .625 Diameter
26 638-0020A RH Axle Assembly, .625 Diameter
27 683-0128A Pivot Bar
28 712-0431 Flange Lock Nut, 3/8-16
29 714-0162 Cotter Pin
30 726-0214 Push Cap, .625
31 736-0162 Flat Washer, .64 x 1.0 x .12
33 736-0285 Flat Washer, .635 x 1.589 x .06
34 738-1011 Shoulder Screw, .5 x 2.2, 3/8-16
35 741-0659 Flange Bearing, .632 ID x .937 OD
36 634-0105A Wheel Assembly Complete, 15 x 6 x 6
634-0172 Rim Only w/ Plastic Bearing
734-0255 Air Valve (Not Shown)
734-1731 Tire Only, Square Shoulder
37 734-2290A Hub Cap
38 783-0653D Steering Support Bracket
39 738-0143 Shoulder Screw, 3/8-16
40 736-0331 Bell Washer, .39 x 1.13 x .062
41 710-1260A Self-tapping Screw, 5/16-18 x .75
42 736-0242 Bell Washer, .34 x .872
43 710-0643 Hex Bolt, 5/16-18 X 1
44 783-0656A Axle Bracket RH
45 783-0657A Axle Bracket LH
46 736-3004 Flat Washer
REF.
NO.
PART
NO.
DESCRIPTION
Models D609, G609, U609 & X609
NOTE: For painted parts, please refer to the list of color codes below.
Please add the applicable color code, wherever needed, to the part
number to order a replacement part. For instance, if a part numbered
700-xxxx is painted Powder Black, the part number to order would be
700-xxxx-0637.
Red: 0638
Oyster Gray: 0662
Powder Black: 0637
