Models D609, G609, U609 & X609
REF.
NO.
PART
NO.
DESCRIPTION
1 647-0064 PTO Engage Lever Assembly
2 683-0450 PTO Engage Plate Assembly
3 710-0276 Carriage Screw, 5/16-18 x 1.00
4 710-0520 Hex Cap Screw, 3/8-16 x 1.5
5 710-0831 Hex Cap Screw, 3/8-16 x 5.5
6 710-1238 Hex Head Washer Screw, 5/16-18 x .875
7 712-0229 Push Nut, 3/8
8 712-0431 Flange Lock Nut, 3/8-16
9 712-3004A Flange Lock Nut, 5/16-18
10 712-3010 Hex Nut, 5/16-18
11 714-0470 Cotter Pin, 1/8 x 1.25
12 726-0201 Speed Nut, .3125
13 731-2111A PTO Knob
14 732-1170 Extension Spring, .75 x 6.75
15 732-0991A Belt Guard
16 736-0108 Flat Washer, .510 x .750 x .033
17 736-0119 Lock Washer, 5/16
18 736-0140 Flat Washer, .385 x .62 x .063
19 736-0275 Flat Washer, 5/16
20 736-3000 Flat Washer, .406 x .875 x .059
21 736-0331 Bell Washer, .39 x 1.13 x .062
22 736-3039 Flat Washer, .407 x .812 x .135
23 738-0372B Shoulder Spacer, .380
24 741-0708 Hex Split Flange Bearing
25 747-1112D PTO Engagement Handle
26 747-1286A Belt Keeper Rod
27 748-0415B Spacer, 3/8 x 1.54
28 756-0627B Idler Pulley, 3.5
29 756-1208 Idler Pulley, 4.0
30 783-0744A Engagement Stop
31 783-0891B Deck Stop
32 710-0604A Self-tapping Screw, 5/16-18 x .625
33 732-3080A Compression Spring, 1.28 x 3.5
34 723-0444 Battery Strap
35 738-1020 Shoulder Screw, .625 x .5, 7/16-20
36 736-0407 Bell Washer, .45 x 1.0 x .062
37 712-0459 Flange Lock Nut, 7/16-20
38 783-1031A Hitch Plate
39 783-0349 Battery Tray
40 725-1426 Solenoid, 12-Volt, 100 Amp
41 710-0599 Self-tapping Screw, 1/4-20 x .5
42 736-0222 Lock Washer, 1/4
43 683-0304 Lower Frame Assembly
44 725-1706 12-Volt Battery, 270 CCA
45 710-0703 Carriage Screw 1/4-20 x 0.75
46 712-0271 Hex Sems Nut, 1/4-20
47 712-3087 Wing Nut, 1/4-20
48 732-1165 Extension Spring, .50 x 5.0
49 710-3180 Hex Cap Screw, 5/16-18 x 1.75
50 750-0956 Spacer Cup
51 710-3029 Hex Head Cap Screw, 7/16-20 x 1.25
52 736-0171 Lock Washer, 7/16
53 736-0322 Flat Washer, .450 x 1.25
54 756-0982B Engine Pulley, 3.56 OD x 5.56
55 754-0497 PTO Belt
56 783-0653D Steering Support Bracket
57 711-1044 Keeper Pin, 5/16 x 4.75
58 738-1132 Shoulder Screw 1/4-20
REF.
NO.
PART
NO.
DESCRIPTION
NOTE: For painted parts, please refer to the list of color codes below.
Please add the applicable color code, wherever needed, to the part
number to order a replacement part. For instance, if a part numbered
700-xxxx is painted Powder Black, the part number to order would be
700-xxxx-0637.
Red: 0638
Oyster Gray: 0662
Powder Black: 0637
