37
Models D609G, G609G & X609G
REF.
NO.
PART NO. DESCRIPTION
1.
16606 Bracket: Retainer Hook
2.
618-0565 Spindle Assembly: Pulley
3.
683-0198E Deck Assembly
4.
683-0254 Deck Hanger Bracket LH
5.
683-0440 Brake Assembly: deck
6.
710-0520 Hex Screw 3/8-16 x 1.5
7.
710-0528 Hex Screw 5/16-18 x 1.25
8.
710-0604A TT Screw 5/16-18 x 0.625
9.
710-0650 TT Screw 5/16-18 x 0.875
10.
710-0751 Hex Screw 1/4-20 x 0.620
11.
710-1238 Hex Washer Head Screw
12.
710-1830 TT Screw 1/4-20 x 4.0
13.
710-3151 Hex Screw 5/8-18 x 4.25
14.
710-3180 Hex Screw 5/16-18 x 1.75
15.
711-1534 Pin
16.
712-0337 Hex Nut 5/8-18
17.
712-0417A Flange Nut 5/8-18
18.
712-0431 Flange Lock Nut
19.
712-3004A Flange Lock Nut
20.
712-3006 Hex Nut 1/4-20
21.
712-3010 Hex Nut 5/16-18
22.
712-3027 Lock Nut 1/4-20
23.
714-0470 Cotter Pin
24.
716-3020 Snap Ring
25.
717-1553A Gear: Deck Adjustment
26.
726-0233 Push Nut
27.
731-2486 Belt Cover
28.
732-0306 Compression Spring
29.
732-0470A Extension Spring
30.
732-1165 Extension Spring
31.
734-0973 Deck Wheel
32.
736-0105 Bell Washer
33.
736-0119 Lock Washer
34.
736-0140 Flat Washer
35.
736-0158 Lock Washer
36.
736-0162 Flat Washer
37.
736-0270 Bell Washer
38.
738-0373 Sholder Spacer
39.
741-0524 Bearing
40.
742-0616 Blade
41.
746-0970 Brake Cable
42.
747-1116 Deck Release Rod
43.
748-0331 Shoulder Spacer
44.
750-0932A Spacer
45.
754-0497 V-Belt
46.
754-0498 V-Belt
47.
756-0627B Idler Pulley
48.
756-1202 Double Pulley
49.
783-1025 Chute Stop
50.
783-1291 Idler Bracket
51.
712-3087 Wing Nut
52.
710-0134 Carriage Screw
53.
731-2363 Mulch Plug
REF.
NO.
PART NO. DESCRIPTION
NOTE: For painted parts, please refer to the list of color codes below.
Please add the applicable color code, wherever needed, to the part
number to order a replacement part. For instance, if a part numbered
700-xxxx is painted Powder Black, the part number to order would be
700-xxxx-0637.
Red: 0638
Oyster Gray: 0662
Powder Black: 0637
