39
Model U609H
REF.
NO.
PART NO. DESCRIPTION
1.
16606 Retainer hook: bracket
2.
17116 Deck Brake Assembly
3.
17258C Belt Cover RH
4.
17982 Spindle Plate
5.
618-0240A Spindle Assembly
6.
618-0594 Spindle Assembly: Double Pulley
7.
683-0254 Deck Hanger Bracket LH
8.
683-0265C Deck Assembly
9.
710-0167 Carriage Screw 1/4-20 x 0.5
10.
710-0344 Hex Screw, Special 3/8-16 x 1.5
11.
710-0501 Hex Screw 1/4-20 x 2.0
12.
710-0514 Hex Bolt 3/8-16 x 1.0
13.
710-0528 Hex Bolt 5/16-18 x 1.25
14.
710-0599 TT Screw 1/4-20 x 0.5
15.
710-0650 TT Screw 5/16-18 x 0.875
16.
710-0703 Carriage Screw 1/4-20 x 0.75
17.
710-0751 Hex Bolt 1/4-20 x 0.620
18.
710-0805 Hex Screw 5/16-18 x 1.5
19.
710-1260A LD Screw 5/16-18 x 0.75
20.
710-3180 Hex Screw 5/16-18 x 1.75
21.
711-0993 Belt Guard Pin
22.
711-1554 Pin
23.
712-0271 Sems Nut
24.
712-0417A Hex Flange Nut
25.
712-0431 Lock Nut
26.
712-3004A Lock Nut
27.
712-3006 Hex Nut 1/4-20
28.
712-3010 Hex Nut 5/16-18
29.
712-3027 Lock Nut 1/4-20
30.
714-0470 Cotter Pin
31.
717-1553A Gear: Deck Adjustment
32.
726-0233 Push Nut
33.
732-0306 Compression Spring
34.
732-0429A Extension Spring
35.
732-594A Extension Spring
36.
732-0934 Extension Spring
37.
732-1165 Extension Spring
38.
734-0973 Deck Wheel
39.
736-0105 Bell Washer .375 x .870 x .063
40.
736-0119 Lock Washer
41.
736-0140 Flat Washer
42.
736-0270 Bell Washer
43.
736-0418A Flat Washer
44.
738-0347 Shoulder Spacer
45.
738-0373 Shoulder Screw
46.
746-1107 Cable: Bracket
47.
747-1116 Rod: Deck Release Handle
48.
748-0234 Spacer
49.
750-1320 Spacer
50.
754-0349 V Belt
51.
754-0486A V Belt
52.
756-0627B Idler Pulley
53.
783-0139A Idler Bracket
54.
783-0141 Deck Skirt: Center
55.
783-0142 Deck Skirt RH
56.
783-1025 Chute Stop
57.
783-1348 Belt Cover LH
58.
710-0578 Machine Screw
59.
736-0173 Flat Washer
60.
712-3006 Hex Nut
61.
712-3087 Wing Nut
62.
731-1636 Mulch Plug
REF.
NO.
PART NO. DESCRIPTION
NOTE: For painted parts, please refer to the list of color codes below.
Please add the applicable color code, wherever needed, to the part
number to order a replacement part. For instance, if a part numbered
700-xxxx is painted Powder Black, the part number to order would be
700-xxxx-0637.
Red: 0638
Oyster Gray: 0662
Powder Black: 0637
