SECTION 4: OPERATION
Know the Controls
Read this owner’s manual and safety rules before operating your lawn mower. Compare figure below with your lawn
tractor to learn about the loction and purpose of various controls and adjustments. Save this manual for future
reference. It is very important to follow the instructions and operate the controls properly.
Figure 4
NOTE: Any reference in this manual to the RIGHT or LEFT side of the tractor is observed from operator’s position.
A PTO (Blade Engage) Lever H Cruise Control Button
B Choke Control (Super Bronco only) I Ignition Switch
C Parking Brake Button J Brake Pedal
D Shift Lever K Drive Pedal
E Cup Holder L Cargo Net (not shown)
F Ammeter M Deck Lift Lever
G Throttle Control Lever
I
B
A
H
C
D
E
L
K
J
P
G
M
F
Steering Wheel not shown for clarity.
AMPS
