TI-1G & TI-2G GAS COMBO COOKTOP MANUAL P. 8
III. Cooktop Installation Continued...
Dimensions and Placement for Cut-out in Countertop
4’’ min
4” min
23 3/4’’
14 1/4”
4” min
4” min
4’’ min
4” min
22’’
19 1/2”
4” min
4” min
 Cut a rectangle hole in the countertop where the cooktop is to be placed. The dimensions for the
TI-1G are 14 1/4’’ x 23 3/4’’, and the TI-2G are 19 1/2’’ x 22’’. Please use the “Cut Out Board” includ-
ed in the box.
 The cut out must be placed at least 4’’ for any side of the counter top.
 To achieve ush mounting installation, use a router tool to round corners of the hole cut into the
counter top.
