I. Cooktop Installation Continued...
Clearance Needed for Air Circulation
●
●
Below you will see a diagram of the air flow. Be sure not to block either the intake or exhaust
For proper air circulation, allow at least 3" of clearance from the bottom of the induction
cooker to any shelving or storage. The underside of the countertop should not be closed off
from the cabinetry underneath for better air flow.
DOUBLE BURNER TI-2BN COUNTER INSETINDUCTION COOKTOP MANUAL P.3
