INSTALLATION / OPERATION INSTRUCTIONS
STEP 2
Usinga7/16”wrenchoradjustablewrenchand
1/8”allenwrenchloosenrollerandmove
alongslottedhole.Afteradjustmenthasbeen
madetightenthe
rollerintoplace.
Seeimage10.
TO ADJUST SLIDE DOOR
P-Clip keeps cord
in-place (prevents
cord damage).
Image 6 (Three Door Units ONLY)
STEP 6
Removedoorcordfromrollerbracket.Theblack
plastictabholdingthedoorcordslidesoutthe
back.Seeimages7&8.
STEP 1
Aftercabinetisinstalledinafinallocationand
correctlyleveledcheckforanyopeningswhenthe
slidedoorsarecompletelyclosed.Ifthereare
anygaps/openingsbetweenthecloseddoors
andcabinet,thedoorswillneedtobe
adjusted.
STEP 7
Letthedoorcordslowlyretractbackintothe
doorsidechannel.Theknottiedattheendof
thedoorcordwillkeepthecordfromretracting
allthewaybackintothedoorchannel.See
image9.
(Three Door Units ONLY)
STEP 1
Beforeremovingslidedoordonotusetheside
latch.Tensiononthedoorcordisneededto
executetheseoperationinstructions.Doorscan
notberemovedunlessplacedinspecificlocations
statedintheseinstructions.
STEP 2
Two Door Units:Slidethefrontdoorsoitis
centeredonthecabinet.Thedoorcannotbe
removedunlessitiscentered.Seeimage1for
doorchannelopeningsandimage2for
centeringdoor.
Three Door Units:Slidethemiddledoorto
therightsidesotheglassiscenteredwiththeleft
edgeoftherightsidedoor.Seeimage3.
(Two Door Units ONLY)
(Two Door Units ONLY)
CENTERED DOOR
(Three Door Units ONLY)
TRUE Logo
STEP 5
Slideleftdoortotherightsorightedgelinesup
withtheendoftheTRUELogolocatedatthe
topofthedoorframe.Seeimage6.Thenlift
dooroutoftracksamewayasimage4.
STEP 4
Sliderightdoortotheleftsoleftedgelinesup
withtheleftedgeofTRUELogolocatedabovethe
door.Seeimage5.Thenliftdooroutoftrack
samewayasimage4.
STEP 3
Aftercenteringthedoorliftitupandtilttopof
doortowardsthebackoftheunitsotherollersare
outofthetopchannel.Swingthebottomofthe
dooroutofthebottomchannel.Thenremovethe
doorandsetitdown.Seeimage4.
(TWO DOOR UNITS SKIP TO STEP 6)
TRUE Logo
Gasket fasten to door bottom assures door will
remain in track when unit is placed on uneven
surface.
Door Cord
Knot
SLIDE DOORS
CENTER DOOR
1
2
3
4
5
6
7 8
9
10
