INSTALLATION / OPERATION INSTRUCTIONS
SHELF & ORGANIZER INSTALLATION:
Step 1
A. Hookshelfclipsontoshelfstandards.  
 (seeillustration).
B. Positionallfourshelfclipsequalindistancefromthe
 floorforflatshelves.
C. LowerfrontofgravityfeedTrueTracorganizerstoenable
 properfeed.
WIRE SHELVES:
Wireshelvesareorientedsothatcrosssupportbarsarefacing
down.
NOTE
GDM-5 models include an airflow guard on the rear of shelves to
maintain an air space at the rear of the cabinet. (see illustration).
TrueTrac ORGANIZERS:
TrueTracorganizersforGlassDoorMerchandiserscomewith
apackageofshelfretainerclips.Installcliponthesidetothe
rearoforganizer(seeillustration)toendoforganizerthatrests
againstleftorrightoutsidewall.
Withcorrectinstallation,theretainerclipshouldseparatethe
rearoftheorganizerfromtherearinteriorwallofthecabinet.
NOTE
No retainer clips needed on center
organizers of a GDM-69.
Step 2
Placeshelvesororganizersonshelfclipsmakingsureall
cornersareseatedproperly.
SHELVING INSTALLATION / OPERATION &
LIGHT SWITCH LOCATION
Shelf Installation Tips
1. Installalltheshelfclipsbeforeinstallingtheshelves.
2. Startatthebottomintermsofshelfinstallationandworkyour
wayup.
3. Alwayslaythebackofeachshelfdownontherearclipsbeforethe
front.
WARNING
Do not use pliers or any crimping
tools when installing shelf clips.
Altering shelf clips in any way can
lead to shelving instability.
Install the top tab of the shelf
clip into the proper hole.
Push up on the bottom of the
clip. Bottom tab of the shelf
clip will fit tightly. You may
need to squeeze or twist the
bottom of the shelf
clip to install.
LIGHT SWITCH LOCATION:
LightswitchlocationdependsupontheGDM
model.MostGDMmodelswillhavethelight
switchlocatedontherightsideoftheceiling
insidetheunit.Mostinstancestheswitchis
locatednexttothetemperaturecontrol.GDM-
49’sand72’shavetheswitchlocatedontheright
sideoftheevaporatorhousingalongtheinterior
ceiling.GDM-9’s,5’s,andGDM-5PT’shavethe
switchlocatedontheleftsideoftheceiling.Some
conveniencestoreGDM’shavetheswitchlocated
behindtheslidingdoorsabovethelightbulbfor
exampletheGDM-33SSL-54andtheGDM-
33CPT-54.G4SM-23modelshaveanadditional
switchfortherotatingdisplayshelves.Theswitch
fortherotatingshelvesintheG4SM-23modelsis
locatedunderthesignframe.
