LAE CONTROLLER PARAMETER SETTINGS FOR CELSIUS
For LAE control model AR2-28 ONLY, ALL parameters with a formula
shown need to be converted for Celsius applications.
EXAMPLE:
If current SPL is set for 20 degrees F the formula is (X-32) / 1.8
(20-32) / 1.8 = -6.7 Celsius
AR2-28
SCL 1C ADO
SPL (X-32) / 1.8 AHM
SPH (X-32) / 1.8 AHT (X-32) / 1.8
SP (X-32) / 1.8 ACC
C-H IISM
HYS (X) / 1.8 IISL (X-32) / 1.8
CRT IISH (X-32) / 1.8
CT1 IISP (X-32) / 1.8
CT2 IIHY (X) / 1.8
CSD IIFC
DFM HDS
DFT IIDF
DH1 SB
DH2 DS
DH3 DSM
DH4 DI2
DH5 STT
DH6 EDT
DLI (X-32) / 1.8 LSM
DTO OA1
DTY OA2
DPD CD
DRN INP
DDM OS1 (X) / 1.8
DDY T2
FID OS2 (X) / 1.8
FDD (X-32) / 1.8 T3
FTO OS3 (X) / 1.8
FCM TLD
FDT (X) / 1.8 TDS
FDH (X) / 1.8 AVG
FT1 SIM
FT2 ADR
FT3
ATM
ALA (X-32) / 1.8
AHA (X-32) / 1.8
ALR (X) / 1.8
AHR (X) / 1.8
ATI
ATD
