True SPEC Series User Manual

6
TRUE
SPEC SERIES®: STR, STA & STG, ROLL-IN AND ROLL-THROUGH
www.truemfg.com
6
ROLL-IN & ROLL-THRU RAMP INSTALLATION
Once the cabinet is in its final location and level the roll-in ramp can
be installed. The ramp has three slotted holes in back. These slotted
holes slide over three thumb screws located in the front of the
cabinet near the floor.
Be sure the doors are closing smoothly and not binding up on the
ramp. To adjust door sweeper gasket, loosen slotted thumbscrews.
The gasket can then be moved up or down and side to side. The
gasket should make some contact with the ramp when the door is
closing. This can be checked by opening up the door 3-4" and allowing
the door to close. This process may have to be done several times
before securing the sweeper gasket bracket. Once gasket is properly
adjusted, tighten slotted thumbscrews.
1 2
3 4
DOOR SWEEP GASKET ADJUSTMENT
To adjust door sweeper gasket, loosen slotted thumbscrews. The
gasket can then be moved up or down and side to side. The gasket
should make some contact with the ramp when the door is closing.
This can be checked by opening up the door 3-4" and allowing
the door to close. This process may have to be done several times
before securing the sweeper gasket bracket. Once gasket is properly
adjusted, tighten slotted thumbscrews. See image 5.
5
