24
STEP 2—ROUTE CABLE THROUGH UPRIGHT AND MAIN FRAME ASSEMBLIES CONTINUED
f. Attach the upright cable to the main frame cable attachment point using the cable bolt.
IMPORTANT! A minimum of 1/2" (12.7 mm) of the threaded portion of the cable bolt must be threaded into the cable
attachment point.
NOTE: Secure the cable bolt to the cable attachment point with the jam nut.
8
14
