MAINTENANCE, CARE, CLEANING
CLEANING THE CONDENSER COIL
REFRIGERATED BAKERY & COLD DELI
When using electrical appliances, basic safety precautions should be
followed, including the following:
TOOLS REQUIRED
• Phillips Screwdriver
• Stiff Bristle Brush
• Adjustable Wrench
• Air Tank or CO2 Tank
• Vacuum Cleaner
STEP 1 - Disconnect power to unit.
STEP 2 - Take off rear lower grill assembly by removing two (2)
bottom screws. If necessary, loosen screws holding the top pivot
pins. Swing grill up and remove frame hooks from pivot pins at top
of louver.
STEP 3 - Remove bolts anchoring compressor assembly to frame
rails and carefully slide out (tube connections are flexible).
STEP 4 - Clean off accumulated dirt from condensing coil with a
stiff bristle brush.
STEP 5 - After brushing condenser coil vacuum dirt from coil and
interior floor.
STEP 6 - Carefully slide compressor assembly back into position
and replace bolts.
STEP 7 - Connect unit to power and check to see if condenser is
running.
STEP 8 - Reinstall louver assembly onto unit, tighten all screws.
