Press "FUNC/ENTR", then "0" "2". The display will show:
12/24 hr Format or 12/24 hr Format
24 1
2
Press the up or down arrow keys to toggle between 24 and 12. When the display shows the desired
format, press "FUNC/ENTR" to enter your choice.
3-103 KEYPAD FUNCTION 03 - TIME/DATE ENTRY
Use Function 03 to enter time and date.
Press "FUNC/ENTR", then "0" "3". The display will show:
Date-time or Date-time
UTC L
ocal
Press the up or down arrow keys to toggle between "UTC" and "Local" depending on which you intend
to enter. When the display shows your choice, press "FUNC/ENTR" again and the display will show:
Date-time
MM/DD/YY
where MM is the month, DD is the day and YY is the year. NOTE: Year entries less than 10 will display
as a single digit. Press the right or left arrow keys to move the cursor beneath the digit that you wish to
change. Press the up or down arrow keys to scroll through the possible choices. Alternately, directly
enter the numbers using the keypad. The cursor will advance to the next digit automatically. NOTE:
Although an illegal entry will display, the entry will not be accepted.
Press "FUNC/ENTR" again and the display will show:
Date-time
HH:MM:SS
where HH is the hours, MM is the minutes and SS is the seconds.
Press the left or right arrow keys to position the cursor beneath the digit that you wish to change. Press
the up or down arrow keys to scroll through the possible choices. Alternately, directly enter the
numbers using the keypad. The cursor will advance to the next digit automatically. Press
"FUNC/ENTR" to enter the data. NOTE: Only valid times will be accepted.
3-104 KEYPAD FUNCTION 04 - SERIAL PORT SETUP
Use Function 04 to configure the Serial Port. The as-shipped default values are:
Baud Rate 9600
Data Bits 7
Parity even
Stop bits 1
