142-603.ADD 1 of 1 Rev. A
Addendum for 142-603
Antenna Downconverter Assembly
PHYSICAL SPECIFICATIONS
Antenna Downconverter Size: 4.4 in. dia. x 2.1 in.
(11.17 cm. dia. x 6.85 cm.)
Note: Antenna DownConverter Units are mounted on a 12-inch long PVC nipple with a 3/4-inch
Male Pipe Thread (MPT) on both ends. The above specified overall lengths of the Antenna
DownConverter Units are therefore increased by approximately 11.25 inches, when the
mounting nipple is included.
Antenna DownConverter Weight: 0.60 lb (.272 Kg)
(Including Mtg. Nipple)
Antenna DownConverter Available lengths = 150 - 1500 ft. (standard length 50 ft.)
Cable, RG-58: 2.7 lb (1.23 Kg) per 100 ft.
ANTENNA CABLE DELAY ENTRY/REQUEST
The as shipped default antenna cable delay is +60 nS. When the downconverted antenna is
being used, 150 nS should be added to the cable delay entered.
