DuoC
f
b
d
e
c
a
Figure 1
a = on (summer mode)
b = off
c = on and heating (winter mode)
d = red LED
e = green LED
f = yellow LED EisEx (winter mode)
Start-up
Summer mode
Switch downwards (a).
The LEDs indicate the status of the operating cylinder:
full = green LED illuminated
empty = red LED illuminated
Winter mode
Switch up (c).
In addition to the operating cylinder's status indicator, the
changeover system is heated and this is indicated by the yel-
low LED.
Operating instructions
Technical data
Supply voltage: 12 V
Power consumption, summer mode: 1.5 mA
Power consumption, winter mode with EisEx: 160 mA
Subject to technical changes.
