TruPace E 200 - Step 7: Console Installation

Step 7:
A. Remove the 4 console screws (2) from the back of the computer console.
B. Connect the upper computer cable (3) to the computer console cable (4)
Note: put the excess wire in to the handlebar post
C. Attach the computer console (4) to the handlebar post (49) by using the 4 screws (2)
removed from the console
D. Tighten all bolts now.
Congratulations your Elliptical is now ready to use.
Plug in the power adaptor
Owner’s Manual 10
4
8
2
3
