3. Mechanism

3.1 Replacing the Printer Top Cover (with Keys Control Board)

1. Remove 4 screws as indicated.

2. Remove the cable and unscrew 1 screw to take out the printer top cover (with keys control board).

3. Reassemble the parts in the reverse procedures.
