3.2 Replacing the Keys Control Board

1. Refer 3.1 to remove the printer top cover (with keys control board).

2. Disconnect the cable and unscrew 4 screws as shown.

3. Disconnect the remain 2 cables and take out the LCD board

4. Reassemble the parts in the reverse procedures.
