BW / CW/VW/BWS Series Indicator Technical Manual
- 19 -
-QTY UNIT-
8. RS-232 OUTPUT
8.1. Specifications:
RS-232 output of weighing data
Code : ASCII
Data bits : 8 data bits
Parity :No Parity
Baud rate : 600bps to 9600bps selectable
8.2. Connecter:
RS-232 Output
Pin 2: Input
Pin 3: Out put
Pin 5: Signal Ground
Check Weighing Output
Pin 1 : VB
Pin 4: Vcc 5v (Output)
Pin 5: Com (Ground)
Pin 6: Ok (Output)
Pin 7: Low (Output)
Pin 8: Hi (Output)
Pin 9: Beep (Output)
8. 3. Continuously output protocol
Con1: Weighing mode
k
g
CR
LF
-HEADER1-- - HEADER2- --- WEIGHT DATA --
Counting mode
P
C
S
p
c
s
CR
LF
HEADER1: ST=STABLE US=UNSTABLE
HEADER2: NT=NET GS=GROSS
-WEIGHT UNIT-
TERMINATOR
- QTY -
