BW / CW/VW/BWS Series Indicator Technical Manual
- 3 -
1. SPECIFICATION
VW CW
Model
BW/VW/CW
BW-E
BWS
BWS-E
Display
52mm LCD
1.2” LED
52mm LCD
1.2” LED
Housing
ABS Plastic
SST
Operating Temperature
-10°C - 40°C / 14°F - 104°F
Resolution
1/6000 (OIML Approved)
Key Pad
7 Keys
Power
AC Adaptor (12V/500mA)/ Battery (6V/4Ah)
Calibration
Automatic External
Interface
RS-232 Output Optional
Load cell drive Voltage
Max: 5V/150mA
Load Cells
Up to 4 load cell
ADC
Sigma Delta
ADC Update
≤1/10 second
Stabilization Time
One seconds typical
