C-10 Electrostatic Classifier Model 3082 and SMPS Spectrometer Model 3938
Table C-2
Electrostatic Classifier Firmware Commands List (select)
Command
Title
Description
WSCUSTOMDMAID
Write Custom
DMA Inner
Diameter
WSCUSTOMDMAID sets DMA inner diameter of custom DMA, in
meters. Used by inversion algorithm. Should be followed by a
DOREGSAVE.
Example: WSCUSTOMDMAID 0.01874 sets custom DMA inner diameter
to 1.874 cm.
WSCUSTOMDMAOD
Write Custom
DMA Outer
Diameter
WSCUSTOMDMAOD sets DMA outer diameter of custom DMA, in
meters. Used by inversion algorithm. Should be followed by a
DOREGSAVE.
Example: WSCUSTOMDMAOD 0.03922 sets custom DMA outer
diameter to 3.922 cm.
WSCUSTOMDMATYPE
Write Custom
DMA Type
WSCUSTOMDMATYPE sets the custom DMA type to 1 (cylindrical) or 2
(radial). Used by inversion algorithm. Should be followed by a
DOREGSAVE.
Example: WSCUSTOMDMATYPE 1 sets custom DMA type to cylindrical.
Help Commands
HELP
General help
command
HELP [command] gives more information about a command or type of
command:
DO, list of DO commands and their definitions
RD, list of RD commands and their definitions
RS, list of RS commands and their definitions
RM, list of RM commands and their definitions
WD, list of WD commands and their definitions
WS, list of WS commands and their definitions
[command], returns information about the function of the command
Example: HELP DO will return the list of valid DO commands and their
definitions
Example: HELP RDSN will give definition of RDSN and additional
information about the length of the character string
For Write commands, the instrument returns a response of:
- PARAMETER SENT if syntax and parameter were valid
- ERROR if syntax or command was invalid
For Read or Mode commands, the instrument returns a response of:
- data or data,data,data if syntax and parameter were valid
- ERROR if syntax or command was invalid
