Unpacking and Setting Up 2-3
If a 3081A is purchased, you will receive an additional 3081A Accessory
Kit. Table 2-5 lists the components included in the Model 3081A
Accessory Kit.
Table 2-5
Model 3081A Long DMA Accessory Kit
Qty.
Part Number/
Model Number
Description
1
1030389
Dacron screen assembly
In order to convert a 3085 Nano DMA into a 3085A Nano DMA
(recommended), you must purchase the 3085U upgrade kit. Table 2-6 lists
the components included in the Model 3085A Long DMA upgrade kit.
Table 2-6
3085U Nano DMA Upgrade Kit
Qty.
Part Number/
Model Number
Description
1
N/A
DMA base plate with memory chip (unprogrammed)
1
N/A
Adapter Manifold with bypass flow cap
1
7002311
1/4-inch inlet for Nano DMA
2
N/A
Labels for flow ports
If a 3085A is purchased, you will receive an additional 3085A Accessory
Kit. Table 2-7 lists the components included in the Model 3085A
Accessory Kit for the Nano DMA.
Table 2-7
Model 3085A Nano DMA Accessory Kit
Qty.
Part Number/
Model Number
Description
1
N/A
Inlet Removal Body
1
1030389
Dacron screen assembly
1
N/A
Adapter Manifold with bypass flow cap
If a 3086 is purchased, you will receive an additional 3086 Accessory Kit.
Table 2-8 lists the components included in the Model 3086 Accessory Kit
for the 1nm-DMA.
Table 2-8
Model 3086 1nm-DMA Accessory Kit
Qty.
Part Number/
Model Number
Description
1
N/A
Inlet Removal Body
1
1030389
Dacron screen assembly
1
N/A
Adapter Manifold with bypass flow cap
1
N/A
Horizontal mounting bracket
1
N/A
3/8” to 1/4" reducer
1
N/A
Male outlet port
1
N/A
Outlet port adapter tube
