TSI Instruments 4000 Series User Manual

16
Pin-out for Mini-DIN Connector
Mini-DIN pin-out and cable color code
Mini-DIN
Pin No. Function
Color code for
TSI cable with
tinned wires.
PN 1303584
Computer
female 9 pin
D-Sub
1
Power Input (+5V) Black
2
Power Ground Green
3
Analog Output (+) Red
4
Analog Ground (-) Brown
5
Analog Pressure Input
(+)
Blue
6
RS-232 Receive (in) White 3
7
RS-232 Transmit (out) Yellow 2
8
Logic Ground Gray 5

TSI Instruments 4000 Series Specifications

General

Measurement Parameters	Velocity, Temperature
Data Storage	10, 000 data points
Accuracy	±0.015 m/s or ±1% of reading
Particle Size Range	Not applicable
Display	LCD
Operating Humidity	0 to 95% RH (non-condensing)
