2–2 AEROTRAK™ Remote Airborne Particle Counters
Electrical Connections
The state-of-the art AEROTRAK™ Remote Airborne Particle Counter
(particle counter) supports two types of communications and
connectivity options. The connections are shown below.
Device Connections
24V Power
Input
LVREF
(Laser
Power)
Test
Jack
Diagnostic
Port
RS-422 Pulse
Chassis
Ground
