TSI Instruments 7110 - Tubing Connections; Vacuum Connector and Inlet

Getting Started 2–3
Tubing Connections
Vacuum Connector and Inlet
The vacuum connection at the bottom of the device (next to the
electrical connections) should be connected to a vacuum pump or
central building vacuum supply capable of providing 15 inHg
(38 cmHg) of vacuum at the rated flow rate of 1.0 cfm
(28.3 L/min).
Vacuum
Connector
Inlet
