A-1
APPENDIX A
Specifications
All specifications meet or exceed JIS B9921 and are subject to change
without notice.
Specification Description
Size Range 0.1 to 5.0 um
Channel Sizes -01: 0.1, 0.15, 0.2, 0.25, 0.3, 0.5, 1.0, 5.0 µm
-02: 0.2, 0.5 µm
-03: 0.1, 0.3, 0.5, 5.0 µm
-04: 0.1, 0.2, 0.3, 0.5 µm
Counting Efficiency
(per JIS)
Model 7110-01: 50% at 0.107 µm; 100% for particles >0.15 µm
Model 7110-04: 50% at 0.117 µm; 100% for particles >0.15 µm
Concentration
Limits
20,000 particles/ft
3
at 5% coincidence loss
Light Source Enhanced active cavity HeNe laser
Zero Count Level <1 count / 5 minutes (<0.2 particles/ft
3
) Meets JIS B9921
Flow Rate 1.0 CFM (28.3 L/min)
Calibration NIST traceable
Vacuum
Requirements
External vacuum >15" (38.1 cm) of Hg
Communication
Mode
Pulse output or serial RS-232 output
Status Indicators Power, service, counting and flow
External Surface Stainless steel
Power 24 VDC
Dimensions
(L x W x H)
5.0 in. x 5.0 in. x 17.7 in. (12.7 cm x 12.7 cm x 45 cm)
Weight 11.5 lb (5.23 kg)
Applicable
Standards
CE, JIS B9921
Warranty 2 years. Extended warranties available
Operating
Conditions
50° to 104°F (10° to 40°C) / 20% to 95% non-condensing
Storage Conditions 14° to 122°F (-10° to 50°C) / Up to 98% non-condensing
Compliance
RoHS Marking Yes
Laser Safety Complies with 21 CFR 1040.10 and 1040.11
