3-4 AeroTrak
®
Portable Airborne Particle Counter
Displays the zone where the sample is being taken
by the instrument. Press the icon to display a
summary of information for the zone.
This dropdown box allows selection of a
preconfigured Location to associate the sampled
data to.
The time for each sample.
The Delay displays one of two times:
1. Before the Start button is pressed the Start
Delay time is displayed and then immediately
after the Start button is press the delay time
begins a countdown.
2. During sampling and between cycles (after
the Start Delay has been displayed), the Hold
Delay is displayed and then begins a
countdown.
The volume of air sampled for a given sample.
The specific sample being taken out of the total
number of samples programmed to be taken.
The total number of records in the database/10000
(maximum number of records).
Mode Indicator; refers to the “Data Count Mode”
(see section below).
Start/Stop button to begin and end sampling in the
configured mode.
Press to print the current sample to the optional
printer.
