Chapter 5: Changing Flow Hoods 35
Figure 17: 1 ft × 5 ft (305 mm × 1525 mm) hood and frame. The support poles always cross as
pairs at the front and back of the fabric hood. For the 1 ft
× 5 ft (305 mm × 1525 mm), the support
poles are inserted into the inside ferrule locations.
2
1
3
1
2
3
5
5
