2.2 Output Switching
A1/A2 These buttons select either:
- the Analogue Left or Right signals of the metered Input.
DIM Approximately 16dB of attenuation is switched into the
audio path
CUT/MUTE The front panel button CUT(s) the signal to all O/Ps.
Remote Mute of either or both of the LS O/Ps and
Variable Line O/Ps are possible via a rear connector. A
ground is required on the appropriate pin to activate the
MUTE condition.
VOLUME The Headphones O/P and the Variable Line O/P may be
varied.
