TSL AMU2-2MA - Pin-out Details; Analogue XLR Connectors

AMU2-2MA MKIII 12 ISSUE 1
4.0 Pin-out Details
4.1 Analogue XLR Connectors
XLRS PIN FUNCTION
ANALOGUE 1 1 GND
ANALOGUE 1 2 1 IN+
ANALOGUE 1 3 1 IN-
ANALOGUE 2 1 GND
ANALOGUE 2 2 2 IN+
ANALOGUE 2 3 2 IN-
ANALOGUE 3 1 GND
ANALOGUE 3 2 3 IN+
ANALOGUE 3 3 3 IN-
ANALOGUE 4 1 GND
ANALOGUE 4 2 4 IN+
ANALOGUE 4 3 4 IN-
ANALOGUE OUT
1 GND
ANALOGUE OUT
2 OUT+
ANALOGUE OUT
3 OUT-
