Control Ports
Control ports 1,2,5,6, 7 & 8 – Serial RS422
Pin Numbers
Signal
Pin Numbers
Signal
1
0v/Chassis
6
0v
2
TX
-
7
TX+
3
RX+
8
RX
-
4
0v
9
0v
5
-
Control Port 3 – Serial RS232 (Maintenance port)
Pin Numbers
Signal
Pin Numbers
Signal
1
-
6
-
2
RX
7
RTS
3
TX
8
CTS
4
DTR
9
-
5
0v
Control Port 4 - Serial RS422 Display Ports
RJ45 DISPLAY CONNECTORS
1
0v
2
0v
3
RX
-
4
TX+
5
TX
-
6
RX+
7
+24v
8
+24v
The Display ports are wired pin to pin, all 8 display ports are paralleled and are addressed as port 4.
UMD displays should be distributed evenly between the eight display drive outputs on the TM2+
controller. Cables to the UMDs should be screened CAT5 cable, in order to conform with European
CE requirements it is recommended that CAT5E FTP cable is used
