TSL Tallyman TMC-1 User Manual

TallyMan V1.81 on
|
Installation
33
Serial Ports
Serial Port 1 – RS232
Pin Numbers
Signal
Pin Numbers
Signal
1
DCD
6
DSR
2
RX
7
RTS
3
TX
8
CTS
4
DTR
9
RI
5
0V/Chassis
Serial Port 2 – RS422
Pin Numbers
Signal
Pin Numbers
Signal
1
TX
-
6
-
2
TX+
7
-
3
RX+
8
-
4
RX
-
9
-
5
0v/Chassis
Serial Ports 3 -18 – RS422
Important Note – The pinout of the expansion card RS422 ports will differ from the RS422 serial
port 2.
Different expansion cards have been used over time dependant upon customer demand and
availability. The information booklet for the expansion card fitted to your units will be included with
your TMC. If you no longer have the information booklet please contact support@tsl.co.uk with the
serial number of your TMC for details.
