TTI FABRICATION CPST-65 - Technical Parameters

4
3. TECHNICAL PARAMETERS
MODEL STRATOS 40 STRATOS 50 STRATOS 65
STRATOS 80 STRATOS 100 STRATOS 120
Heating capacity 40000 BTU 50000 BTU 65000 BTU 80000 BTU 100000 BTU 120000 BTU
Breaker 20A 20A 30A 40A 40A 50A
Voltage
230V
Frequency/phase 60Hz/1Ph
Current* 6.2 A 8.7A 10.4 A 14.6 A
20 A 24 A
Heating power* 1.5 KW 2.1 kW 2.7 kW 3.6 kW 4.5 kW 5.7kW
Current** 6.9 A 9.5A 11.4 A 15.9 A 21.6 A 26A
Heating power** 1.7 KW 2.4 kW 3.2 kW 4.3 kW 5.4 kW 5.9 kW
Compressor RLA/LRA 7.8A/43.5A 10.7A/57.5A 13.4A/75A 17.9A/90A 38.4A/139A 37.5A/168A
Fan motor rating 0.43 A 0.58 A 0.74 A 0.92 A 1.8 A 1.8 A
Design pressure (High) ≥500 PSIG ≥500 PSIG ≥500 PSIG ≥500 PSIG ≥500 PSIG ≥500 PSIG
Design pressure (Low) ≤250 PSIG ≤250 PSIG ≤250 PSIG ≤250 PSIG ≤250 PSIG ≤250 PSIG
Noise Level 50 53 53 53 55 55
Refrigerant (R410A) 40 oz (1.13 kg) 48oz (1.36 kg) 56oz (1.59 kg) 64oz (1.81 kg) 88 oz (2.49 kg) 92 oz (2.6kg)
Net weight 45 KG 60 kg 65 kg 75 kg 85 kg 95 kg
Water circulation flow 15-45 GPM 15-45 GPM 15-45 GPM 15-45 GPM 15-45 GPM 15-45 GPM
Test conditions: All tests were performed at a 700M altitude.
*Air temperature: 80°F, Water temperature: 80°F, Humidity: 80%
**Air temperature: 80°F, Water temperature: 95°F, Humidity: 80%
3.1 Remarks:
• This product can work well with temperatures between 7°C to 35°C (45°F-95℉). Efficiency
will not be guaranteed out of this range and parameters are different under various conditions.
• Related parameters are subject to adjustment periodically for technical improvement without
further notice. For details, please refer to nameplate.
• Machine has heat function only
Note：The swimming pool heater must be grounded well.
3.2 Options for protecting devices.
Model
STRATOS 40
STRATOS 50 STRATOS 65 STRATOS 80
STRATOS 100 STRATOS 120
Breaker Rated current (A) 20 20 30 40 40 50
Fuse (A) 20 20 30 40 40 50
