TTI CPX200 - Page 18

Part No. Position Description
23685-0002 CAP 1N0J 100V P/P C4,104
23685-0007 CAP 100NK 160V P/P P10 C45,145
25021-0901 DIO 1N4148 B/R D1,2,3,5,6,8,9,11-17,24,101,102,103,105,
106,108,109, 111-117,124
25115-0907 DIO 1N4002 B/R D7,10,107,110
25130-0903 DIO ZEN 5V1 W4 D4,104
25211-9302 RECTIFIER BRIDGE W02G BR1,101
25336-5590 TRAN PNP BC559C Q3,103
25380-0229 TRAN NPN BC549 Q2,4,5,102,104,105
25601-0470 TRAN MOSFET N CHAN 2N7000 Q1,101
27001-0020 OPTO-COUPLER CNY17-3 OPT2,102
27001-0030 OPTO-COUPLER HCPL-4503 OPT3,4,103,104
27103-0020 IC LM339 IC4,104
27106-0520 IC OP-07 IC1,2,6,17,101,102,106,117
27153-0030 IC 7109 IC12,112
27160-0014 IC V/REG 7905 IC10,110
27160-0017 IC V/REG 7812 IC8,108
27160-0440 IC V/REG LM2940CT5 IC9,109
27161-0120 IC V/REF ZN404/ZRA245 2.45V D23,123
27168-0020 IC UC3846N IC5,105
27226-0510 IC 4051B IC13,14,113,114
27250-2000 IC MCU8 PIC16C55XT-P IC11,111
28502-0010 RESONATOR CER 4MHZ CSA4.00MG XL1,101
35555-2250 PCB - CONTROL
PCB ASSY - MAIN (44115-0800)
Part Number Description Position
20030-0263 WASHER M3 ZPST FOR D3,4,103,104, PCB, IEC
20037-0301 WASHER M3 SHK/PROOF I/T ZPST E,E1,E2
20038-9501 WASHER M3 Spring FOR D3,4,103,104, PCB, IEC
20062-9303 SCREW NO 6x0.5in. PNHDPZ ST/AB FOR SK1,101
20062-9305 SCREW No.6x3/4in. Pozi. Pan MAIN/CONTROL PCB PILLARS
20205-0610 STUD M3 X 10 KFH-M3-10ET W3,4,103,104, IEC INLET
20210-0101 NUT M3 ZPST FOR D3,4,103,104, IEC INLET
20234-0025 SCREW M3 X 12 PNHDPZ ZPST FOR D3,4,103,104
20234-0027 SCREW M3 X 6 PNHDPZ ZPST FOR PCB SPACERS
