Part No. Position Description
23209-5100 RES 1M00F W75 MF 100PPM R3
23296-0020 RES 0R01D 4 TERM 30PPM PBV R14,114
23379-1100 RES PS/H 100R Cermet 10MM VR1,101
23386-0010 VARISTOR V275LA20A VDR1
23386-0030 THERMISTOR - INRUSH LIMITER 4A RT1
23388-0030 THERMISTOR PTC 2322.661.15693 PTC1,2,101,102
23424-0459 CAP 4N7 250V AC CER Y RATED C6,7
23556-0230 CAP 1000UM 200V ELEC C1,2
23556-0222 CAP 100U 385/400V ELEC C12,112
23556-0225 CAP 2200U 50V ELEC LOW ESR C14,114
23557-0612 CAP 1U0 50V ELEC P2 C22,23,25,122,123,125
23557-0655 CAP 470U 35V ELEC P5 C61,161
23557-0659 CAP 47U 25V ELEC P2 C63,163
23557-0676 CAP 470U 63V ELEC P5 C15,16,115,116
23620-0246 CAP 100NK 63V P/E P5 C19,21,24,26,27,62,119,121,124,126,
127,162
23620-0261 CAP 100NK 400V P/E C17,18,117,118
23620-9007 CAP 10NK 100V P/E P5 C13,113
23684-0010 CAP 470NK 250VAC X2 P/P P27.5 C5,8,9
23687-0010 CAP 1N0F 400V P/P AXIAL C10,11,110,111
25031-0060 DIO BYV27 D5,105
25031-0070 DIO BYV29-400 D1,2,101,102
25031-0080 DIO BYV32E D3, 4,103,104
25117-0020 DIO 1N5401 D6,106
25130-0207 DIO ZEN 15V W4 D9,109
25131-0224 DIO ZEN 18V 1W3 D7, 8,107,108
25211-0302 BRIDGE RECTIFIER D5SB60 BR1
25211-9302 RECTIFIER BRIDGE W02G BR2,102
25601-0440 TRAN MOSFET N CHAN 500V 10A Q1, 2,101,102
27160-0015 IC V/REG 78L15 TO92 (NS) IC16,116
27168-0100 IC IR2110 MOSFET DRIVER IC1,101
35555-2270 PCB - MAIN
