# Code Function
10 Output always off at power-up (factory default)
11 Output status at power-up same as at last power-down
20 LOGIC OUT 'closed' for Output ON, 'open' for Output OFF (factory default)
21 LOGIC OUT ‘closed' for Output OFF, 'open' for Output ON
22 LOGIC OUT ‘closed’ for any trip
23 LOGIC OUT ‘open’ for any trip
24 LOGIC OUT ‘closed’ for UNREG
25 LOGIC OUT ’open’ for UNREG
26 LOGIC OUT ‘closed’ for CI (current limit)
27 LOGIC OUT ‘open’ for CI (current limit)
30 Buzzer on. A single beep indicates a wrong entry (factory default)
31 Buzzer off
40 V CONTROL and I CONTROL both selected (factory default)
41 V CONTROL only selected
42 I CONTROL only selected
50 V CONTROL and I CONTROL scaling 0 to 10 Volts (factory default)
51 V CONTROL and I CONTROL scaling 0 to 5 Volts
60 LOGIC IN ignored (factory default)
61 LOGIC IN active enables output
62 LOGIC IN active disables output
70 Tracking always off (i.e. independent mode) at power-up (factory default)
71 Tracking at power-up same as at last power-down
90 LCD contrast adjustment
91 Restores factory defaults, including these # settings
99 Enter calibration mode. Refer to Service Manual.
Factory Default Settings
The ex-factory default settings (which will apply at first power-up) are as follows:
Voltage: 0.000V
Current Limit: 1.00A
OVP: 90.0V
OCP: 55.0A
Output: Output off; local sense, damping off.
# Settings: 10, 20, 30, 40, 50, 60, 70 active
