TTI TCB-880 - Page 23

37 LCD DISPLAY SDMA2295B FOR TCB-880 SANTECH MAN 1 1 LCD801
38 SW TACT SKTS-1102A SEKWANG SEKWANG MAN 8 8
SW801, SW802, SW803, SW804, SW805,
SW806, SW807, SW808
39 SW SLIIDE SKS-22021T SEKWANG SEKWANG MAN 3 3 SW101, SW102, SW201
40 RESONATOR 4.0MHz ZTA4.00MG D.TRON D.TRON MAN 1 1 X801
MAIN BODY ASS'Y
42 CONNECTOR CH-239(A)-M SAMWOO MAN 1 1 J701 ECO041215-01
43 TRANSISTOR KTA1658 KEC MAN 1 1 Q911
44 TRANSISTOR 2SC2078 SANYO YANG WON MAN 1 1 Q704
45 IC KIA7217AP KEC MAN 1 1 IC201
46 POWER CODE 2PIN PLUG ASS'Y FINE FINE MAN 1 1 J900
MAIN PCB AUTO ASS'Y
47 PCB MAIN FR-4 / R-1 MULTI SMD 1 1 ECO050809-02
48 CHIP RESISTOR 0 1/16W 5% T 1608 PHILIPS SMD 3 3 R108, R137, R201 ECO050328-01
48 CHIP RESISTOR 1 1/16W 5% T 1608 PHILIPS SMD 1 1 R706
49 CHIP RESISTOR 10 1/16W 5% T 1608 PHILIPS SMD 2 2 R133, R301
50 CHIP RESISTOR 100 1/16W 5% T 1608 PHILIPS SMD 6 6 R104, R109, R134, R168, R314, R401
51 CHIP RESISTOR 1K 1/16W 5% T 1608 PHILIPS SMD 19 19
R126, R164, R182, R183, R187, R200,
R222, R234, R238, R308, R312, R410,
R501, R571, R572, R955, R956, R957,
R958
ECO050408-02
52 CHIP RESISTOR 10K 1/16W 5% T 1608 PHILIPS SMD 16 16
R123, R157, R161, R185, R315, R321,
R322, R323, R324, R412, R413, R414,
R703, R821, R823, R914
ECO050418-02
ECO050715-01
53 CHIP RESISTOR 100K 1/16W 5% T 1608 PHILIPS SMD 9 9
R140, R142, R159, R186, R188, R202,
R233, R309, R311
54 CHIP RESISTOR 2M 1/16W 5% T 1608 PHILIPS SMD 1 1 R405
ECO050422-01
ECO050715-01
55 CHIP RESISTOR 1.2K 1/16W 5% T 1608 PHILIPS SMD 1 1 R181
56 CHIP RESISTOR 1.5K 1/16W 5% T 1608 PHILIPS SMD 2 2 R742, R924
57 CHIP RESISTOR 15K 1/16W 5% T 1608 PHILIPS SMD 3 3 R155, R166, R235
58 CHIP RESISTOR 150K 1/16W 5% T 1608 PHILIPS SMD 1 1 R701
59 CHIP RESISTOR 2.2 1/16W 5% T 1608 PHILIPS SMD 1 1 R711
60 CHIP RESISTOR 220 1/16W 5% T 1608 PHILIPS SMD 2 2 R169, R702
61 CHIP RESISTOR 2.2K 1/16W 5% T 1608 PHILIPS SMD 13 13
R01
,
R131
,
R203
,
R237
,
R307
,
R402
,
R817, R822, R912, R922, R923, R961,
ECO050408-02
62 CHIP RESISTOR 22K 1/16W 5% T 1608 PHILIPS SMD 7 7
R963
R132, R162, R172, R175, R302, R304,
R305
63 CHIP RESISTOR 220K 1/16W 5% T 1608 PHILIPS SMD 2 2 R171, R177
64 CHIP RESISTOR 2.2M 1/16W 5% T 1608 SMD 1 1 R153
65 CHIP RESISTOR 2.7K 1/16W 5% T 1608 PHILIPS SMD 1 1 R167
66 CHIP RESISTOR 27K 1/16W 5% T 1608 PHILIPS SMD 2 2 R102, R403
67 CHIP RESISTOR 33 1/16W 5% T 1608 PHILIPS SMD 1 1 R204 ECO050422-01
68 CHIP RESISTOR 33K 1/16W 5% T 1608 PHILIPS SMD 2 2 R404, R407
69 CHIP RESISTOR 3.3M 1/16W 5% T 1608 PHILIPS SMD 1 1 R135
70 CHIP RESISTOR 390 1/16W 5% T 1608 PHILIPS SMD 1 1 R156
71 CHIP RESISTOR 39K 1/16W 5% T 1608 PHILIPS SMD 2 2 R163, R306
72 CHIP RESISTOR 47 1/16W 5% T 1608 PHILIPS SMD 3 3 R184, R705, R913
