TTI TCB-880 - Parts List

NAME & DESCRIPTION VENDOE CODE
Q'ty
Location NO
ITEM MAKER VENDOR ASS'Y TCB TCB REMARKS
880 880B
* ELECT Parts
COVER ASS'Y
1 SPEAKER 77AR000-8P-4D29 ASAHI MAN 1 1 SPK201 ECO041217-03
2 WIRE HARNESS PH-2PIN TO OPEN UL1007 #26 L=200mm FINE FINE MAN 1 1 J204
ESCUTCHEON ASS'Y
3 PCB VOLUME 1LAYER MULTI MAN 1 1
4 PCB CHANNEL 1LAYER MULTI MAN 1 1
5 FILM RESISTOR 10K 1/8W 5% ST MAN 1 1 R400
6 VR A10K SJ161VS 25SK A10K SEJIN SEJIN MAN 1 1 VR101 ECO041217-03
7 VR B50K SJ161V 20SK B50K SEJIN SEJIN MAN 2 2 VR103, VR401 ECO041217-03
8 VR B10K SJ161V 20SK B10K SEJIN SEJIN MAN 1 1 VR102 ECO041217-03
9 SW ROTARY SJ-PS2101 20SK SEJIN SEJIN MAN 1 1 SW811 ECO041217-03
10 COIL AXIAL 6.8UH LAL03TB6R8K MAN 4 4 L501, L502, L504, L506
11 WAFER 3PIN PH-3A 180C FINE FINE MAN 2 2 J103, J104
12 WIRE HARNESS PH-3PIN*2 UL1007 #26 L=30MM FINE FINE MAN 1 1 J103 --- J104
13 WAFER 16PIN PH-16A 180C FINE FINE MAN 1 1 J101
14 WIRE HARNESS PH-16PIN*2 UL2468 #26 L=70MM FINE FINE MAN 1 1 J101 --- J102 ECO041215-01
15 WIRE HARNESS PH-6PIN TO OPEN UL1007 #26 L=70MM FINE FINE MAN 1 1 J502
16 CONNECTOR SOCKET N-16-6(RPCB)-M SAMWOO MAN 1 1 J501
17 HEAT SINK TUBE diameter 4 mm x 15mm MAN 6 6 ECO050321-01
LCD PCB ASS'Y
18 PCB LED FR-4 2 LAYER 1.0T MULTI MAN 1 1
19 PCB DISPLAY (FRONT) FR-4 2 LAYER 1.6T MULTI MAN 1 1
20 CHIP RESISTOR 1K 1/16W 5% T 1608 PHILIPS SMD 2 2 R810, R818
21 CHIP RESISTOR 10K 1/16W 5% T 1608 PHILIPS SMD 5 5 R805, R806, R807, R811, R814
22 CHIP RESISTOR 100K 1/16W 5% T 1608 PHILIPS SMD 1 1 R804
23 CHIP RESISTOR 1M 1/16W 5% T 1608 PHILIPS SMD 1 1 R803
24 CHIP RESISTOR 2.2K 1/16W 5% T 1608 PHILIPS SMD 6 6 R209, R832, R833, R834, R835, R836
25 CHIP RESISTOR 220K 1/16W 5% T 1608 PHILIPS SMD 1 1 R808
26 CHIP RESISTOR 47K 1/16W 5% T 1608 PHILIPS SMD 16 16
R812, R816, R831, R851, R852, R853,
R854, R855, R856, R857, R858, R859,
R861, R862, R863, R864
27 CHIP CERAMIC 0.01UF 1608 PHILIPS SMD 2 2 C806, C807
28 CHIP CERAMIC 1UF 1608 PHILIPS SMD 1 1 C805
29 CHIP CERAMIC 68PF 1608 PHILIPS SMD 2 2 C801, C802
30 CHIP TANTAL 10uF/16V A TYPE SMD 1 1 C811
31 CHIP TRANSISTOR KRA101S SOT-23 KEC SMD 1 1 Q803
32 CHIP TRANSISTOR KRC101S SOT-23 KEC SMD 1 1 Q802
33 CHIP TRANSISTOR KRC104S SOT-23 KEC SMD 1 1 Q801
34 LED VOL BACK LIGHT CHIP LED IWS-164-BXWF ITSWELL SMD 14 14
D954, D955, D956, D957, D958, D959,
D960, D963, D964, D965, D967, D968,
D951, D952
ECO041217-03
ECO050325-04
ECO050511-02
35 IC EEPROM AT24C02 ATMEL SMD 1 1 IC802
36 IC CPU TMP87PP21DF TOSHIBA SMD 1 1 IC801 ECO041217-03
SECTION3 PART LIST
