109 CHIP CERAMIC 6PF 1608 PHILIPS/SAMSUNG SMD 2 2 C317, C321
110 CHIP CERAMIC 68PF 1608 PHILIPS/SAMSUNG SMD 3 3 C97,C131, C732
111 CHIP CERAMIC 680PF 1608 PHILIPS/SAMSUNG SMD 1 1 C414
112 CHIP CERAMIC 82PF 1608 PHILIPS/SAMSUNG SMD 2 2 C406, C707
113 CHIP CERAMIC 8PF 1608 PHILIPS/SAMSUNG SMD 1 1 C326
114 CHIP TANTAL 2.2uF/16V A TYPE SMD 1 1 C301 ECO050418-02
115 CHIP TRANSISTOR KTK211 SOT-23 KEC SMD 2 2 Q102, Q103
116 CHIP TRANSISTOR KRA102S SOT-23 KEC SMD 1 1 Q163
117 CHIP TRANSISTOR KRC101S SOT-23 KEC SMD 10 10
Q104, Q105, Q153, Q222, Q305, Q311,
Q312, Q313, Q953, Q954
ECO050408-02
118 CHIP TRANSISTOR KRC102S SOT-23 KEC SMD 1 1 Q914
119 CHIP TRANSISTOR KRC110S SOT-23 KEC SMD 3 3 Q121, Q960, Q961 ECO050715-01
120 CHIP TRANSISTOR KRC111S SOT-23 KEC SMD 4 4 Q202,Q502, Q962, Q963 ECO050408-02
121 CHIP TRANSISTOR KRC112S SOT-23 KEC SMD 5 5 Q122, Q152, Q154, Q913, Q922
122 CHIP TRANSISTOR KTA1504S SOT-23 KEC SMD 4 4 Q164, Q233, Q912, Q924
123 CHIP TRANSISTOR KTC3875S SOT-23 KEC SMD 9 9
Q151, Q181, Q182, Q183, Q234, Q742,
Q921, Q923, Q931
124 CHIP TRANSISTOR KTC3880S SOT-23 KEC SMD 8 8
Q101, Q161, Q162, Q301, Q302, Q303,
Q701, Q702
125 DIODE ZENER Z02W5.1V SOT-23 KEC SMD 1 1 DZ181
126 DIODE ZENER Z02W5.6V SOT-23 KEC SMD 1 1 DZ931
127 DIODE ZENER Z02W8.2V SOT-23 KEC SMD 1 1 DZ921
128 DIODE SI CHIP KDS181 SOT-23 KEC SMD 1 1 D401
129 DIODE SI CHIP KDS184 SOT-23 KEC SMD 14 14
D102, D103, D105, D171, D180, D181,
D233, D571, D572, D741, D742, D921,
D961, D962
ECO050408-02
130 DIODE SI CHIP KDS226 SOT-23 KEC SMD 1 1 D101
131 DIODE VARICAP KDV251S SOT-23 KEC SMD 2 2 D301, D302
132 IC PLL LC7152NM SANYO YANG WON SMD 1 1 IC301
133 IC OP AMP KIA358F KEC SMD 1 1 IC102
134 IC OP AMP KIA4558F KEC SMD 1 1 IC401
135 IC FM IF TK14489V TOKO SMD 1 1 IC101
MAIN PCB MANUAL ASS'Y
135 FILM RESISTOR 2.2 1/2W 5% ST MINI MAN 1 1 R712
136 FILM RESISTOR 10 1/2W 5% ST MINI MAN 1 1 R921
137 FILM RESISTOR 470 1/2W 5% ST MINI MAN 2 2 R951, R954 ECO050418-02
138 FILM RESISTOR 4.7K 1/2W 5% ST MINI MAN 1 1 R713
139 FILM RESISTOR 1K 1W 5% ST MINI MAN 2 2 R952, R953 ECO050418-02
140 METAL OXID RESISTOR 10 2W 5% ST BULK MAN 1 1 R208
141 RESISTOR SEMI 100KB PH0630NOX0X-HA1-B104 SOUNDWELL MAN 2 2 RV571, RV572
142 RESISTOR SEMI 2.2KB PH0630NOX0X-HA1-B222 SOUNDWELL MAN 1 1 RV231
143 RESISTOR SEMI 22KB PH0630NOX0X-HA1-B223 SOUNDWELL MAN 1 1 RV401
144 RESISTOR SEMI 4.7KB PH0630NOX0X-HA1-B472 SOUNDWELL MAN 2 2 RV131, RV911
145 ELECT CAPACITOR 1UF KR1-16V010MA 5X11 DONGXIANG MAN 3 3 C167, C407, C408
146 ELECT CAPACITOR 10UF KR1-16V100MA 5X11 DONGXIANG MAN 8 8
C232, C331, C332, C333, C913, C921,
C931 ,C964
ECO050328-01
147 ELECT CAPACITOR 100UF KR3-16V101MA 5X11 DONGXIANG MAN 2 2 C821, C923
148 ELECT CAPACITOR 1000UF KR1-16V102MF 10X20 DONGXIANG MAN 4 4 C207, C213, C217, C912
